Microwave Device Simulation Software & Components

Application Examples

We simulate the performance of a leaky wave antenna implemented on a slotted substrate integrated waveguide. The antenna produces narrow beams that scan from near broadside to endfire as the frequency increases. The antenna has a wide impedance bandwidth and efficiency that improves with an increase in the operating frequency.

Application Examples

This example uses XFdtd to simulate the performance of a low cost, chipless RFID system. The RFID tag is comprised of two ultrawide band monopole disk antennas mounted in a cross-polarized configuration combined with a microstrip line adjacent to six varying size spiral resonators which each represent a single bit in the RFID tag code. The system is validated using two cross-polarized log periodic dipole arrays as the send and receive devices.

Application Examples

A band-pass filter is simulated showing the use of substrate integrated waveguides in XF.

Videos

In this video, a Remcom engineer walks through the steps to set up and tune a Ku Band microstrip lens in Rotman Lens Designer (RLD). Included is a discussion of the various options for exporting the file and importing into XFdtd EM Simulation Software, including the use of a customized script to automatically set up the ports and include the material properties.

Videos

This video is a tutorial that shows a rectangular waveguide being built using XF’s modeling techniques. You will learn how to use XF’s built-in materials library, create the waveguide interface, solve for and display lowest-order TE modes, and display the field results.

Videos

This short video clip highlights the waveguide ports feature in XF.

Publications

An area source for exciting a microstrip line in an FDTD simulation is proposed and studied in this paper.

Publications

Click on the title to view or download this publication.

Publications

This paper demonstrates the design of Rotman lens for ESM sensor application in operation band 32-38 GHz. The initial design is created in Remcom’s Rotman Lens Designer and then verified against experimental measurements. Parameters of the realized prototype are presented and methods of increasing its performance are outlined.
