Radar and Scattering Analysis Software

Webinars

Learn about WaveFarer's new features for automotive and indoor radar applications, including diffuse scattering from rough surfaces such as roads and the ability to transmit through walls, windows, and more. Remcom will demonstrate these and other new capabilities using a sample drive scenario as well as an indoor mmWave sensor scenario.

Application Examples

Basic bistatic scattering is demonstrated for a conducting sphere with XF results compared to measurements.

Application Examples

Crosshole Ground Penetrating Radar is examined in XFdtd. The ability to find COP and MOG data is shown.

Application Examples

This example details the setup and execution of RCS calculations using XGtd’s X3D PO MEC model and compares the predictions to those made using XFdtd.

Videos

Using WaveFarer's included scripts, users can leverage Remcom's XGtd path viewer to generate ray path animations. This clip demonstrates the capability by showing backscatter in an indoor scenario, visualizing how waves diffract through doorways and penetrate walls.

Videos

WaveFarer’s diffuse scattering model increases the fidelity of the simulation by revealing how paths interact with rough surfaces, leading to additional clutter in radar returns.

Videos

This short animation shows predicted RCS from an air traffic control radar with an aircraft flying over a wind farm, before and after the static ground clutter (returns from terrain) are filtered out.

Publications

This paper discusses the FDTD method to simulate the behavior of plasma materials using Remcom’s XFdtd 3D EM Simulation Software and presents validation in one- and three-dimensions.

Publications

In this article, the author utilizes the PO solver available in Remcom's WaveFarer® radar simulation tool to simulate back-scatter from the chest of an animated human model and compare the predictions against 28.5 GHz measurements collected by the National Institute of Standards and Technology (NIST).

Publications

Wind turbines located near radar installations can significantly interfere with a radar’s ability to detect its intended targets. Remcom’s XGtd software is a high frequency solver capable of calculating the radar cross section of electrically large objects. In this paper, interference from wind turbines is predicted using XGtd simulations.
