Wind Turbines and Impact on Radar Returns

Application Examples

In this example, the impacts of a lightning strike on a simplified wind turbine are compared for different strike locations by comparing the magnetic fields created inside the nacelle.

Videos

This short animation shows predicted RCS from an air traffic control radar with an aircraft flying over a wind farm, before and after the static ground clutter (returns from terrain) are filtered out.

Videos

Remcom’s XGtd can simulate the propagation paths of fields interacting with two wind turbines in close proximity. XGtd then generates a movie that shows the directions and magnitudes of the strongest propagation paths, including multipath occurring between the turbines.

Publications

Wind turbines located near radar installations can significantly interfere with a radar’s ability to detect its intended targets. Remcom’s XGtd software is a high frequency solver capable of calculating the radar cross section of electrically large objects. In this paper, interference from wind turbines is predicted using XGtd simulations.

Publications

Radar scattering from a turbine’s moving blades can interfere with Doppler radar systems, producing ghost images. Understanding the scattering properties of a blade helps to mitigate any potential issues. This study compares the radar cross section of a metal turbine blade, a hollow fiberglass turbine blade, and a hollow fiberglass turbine blade with a metal spar using XFdtd.a

Publications

Wind turbines located near a radar installation can significantly interfere with the ability of the radar to operate properly. Remcom has performed a number of research efforts into the impact that wind turbines and wind farms have on radar returns for Air Traffic Control (ATC) radar, early warning radar, weather radar, and instrumentation radar. Highlights of some of these effects and relevant samples and white papers are provided in this brief overview.
