Remcom announces 5G antenna array design features in the latest release of XFdtd® 3D EM Simulation Software, including workflow enhancements for modeling complex devices at millimeter wave frequencies.
The advanced antenna systems in modern devices leverage beam steering and multiple data stream transmission to meet 5G throughput requirements. XFdtd provides performance metrics for 5G beam steering applications by simulating the radiation pattern for different array or subarray phasing conditions that are used to steer a beam. By considering the optimal gain levels of the various beam steering scenarios, XFdtd plots the cumulative distribution function (CDF) of the effective isotropic radiated power (EIRP) of the array as a whole. The EIRP is an important indicator of the array’s quality of coverage and is particularly valuable for analyzing 5G-capable devices that support multi-user MIMO (MU-MIMO) use cases.
Rodney Korte, product manager for XFdtd, said, “The CDF of EIRP metric is growing in importance as carriers require devices to meet strict quality thresholds. Our customers designing mobile devices need to measure the gain of many signals propagating in different directions, and Remcom is at the forefront of this emerging technology. The new CDF of EIRP plot is a way to help design engineers prepare their devices for the challenging demands of 5G networks.”
The matching network design workflow has also been enhanced via XFdtd’s integration with Optenni Lab™ matching circuit optimization software. Optenni's optimized matching topology data can now be imported directly into XFdtd, providing users with immediate feedback on how the circuit will behave and eliminating the need to run another simulation. Results such as S-parameters, efficiency, and dissipated power are readily available for analysis of system performance, greatly simplifying the matching process for intricate devices with many frequency bands.
The release also introduces modeling options that improve simulation accuracy for the higher frequencies typical of the antennas in modern devices, including a new feed specifically designed for exciting microstrips, surface current measurement, and a user-defined input for surface roughness of conductors.
For more information on the latest release of XFdtd, please visit Remcom’s website. XFdtd users without an active Remcom Professional Support contract can upgrade to the latest version by contacting sales.
About Remcom: Remcom provides innovative electromagnetic simulation and wireless propagation software for users in the commercial wireless industry and government sectors. Remcom’s products are designed to work together to provide complete and accurate results when modeling propagation with real-world devices in real-world scenarios. Remcom is committed to its customers’ unique needs, offering flexible licensing options for installations of all sizes as well as custom engineered solutions.
