Flexible PCB Design and 2D Sheets

Wrap a full, multi-layer flexible PCB design onto a form in one easy step, or wrap a sheet onto an arbitrarily shaped surface.

XFdtd_Wrapping_Flexible_PCB_and_2D_Sheets

XFdtd's wrapping capability conforms a flat design to an arbitrary surface. This ability supports a full, multi-layer flexible PCB during import so users do not need to wrap each layer manually—simply select the PCB option from the Import menu, provide the form, and let XF do the work automatically.

Read documentation on XF's PCB Import options...

Flexible PCB
Flexible PCB3
Flexible PCB2

XF also includes a Wrap Sheet feature for single-layer designs, such as conformal antennas. Rather than performing a series of bends, users can easily apply geometry to the desired shape without knowing its parameters for a simplified modeling process.

Read documentation on XF's Wrap Sheet capability...
