    XFdtd System Requirements

    System Requirements

    Minimum
    Recommended
    Advanced
    Processor
    Quad Core Intel i3
    Quad Core Intel i7 or better
    Dual Intel Xeon Eight Core Processors
    RAM
    8 GB
    32 GB
    64 GB+
    Display (Requires OpenGL Compatible Adapter)
    1600x900 resolution
    1920x1080 resolution
    1920x1080 (or better) resolution
    XStream® GPU Acceleration1
    NVIDIA CUDA capable GPU card with compute capability 3.5 or higher
    NVIDIA P100
    NVIDIA V100
    Hard Drive Space
    250 GB
    2 TB
    5 TB+

    1. For specific details, please visit NVIDIA's website at https://www.nvidia.com/en-us/data-center/data-center-gpus/

    GUI - Supported Platforms:

    • Microsoft Windows 10 and 11, 64-bit
    • Red Hat Enterprise Linux 7 and 8, Ubuntu 18, 64-bit (and compatible systems)

    Computation Engine - Supported Platforms:

    • Microsoft Windows 10 and 11, 64-bit
    • Red Hat Enterprise Linux 7 and 8, Ubuntu 18, 64-bit (and compatible systems)
    • Inquire for other platform availability.

    The MPI module is available for the following platforms:

    • Open MPI on Red Hat Enterprise Linux 7 and 8, Ubuntu 18, 64-bit (and compatible systems)
    • Inquire for other platform availability.

    NVIDIA Cloud Validated

    • NVIDIA GPU Operator 23.3.2 or newer is required to take full advantage of NVIDIA Cloud Validated features.
    • NVIDIA Driver 450 or newer is required to take full advantage of NVIDIA Cloud Validated features.

    © 2023 NVIDIA and the NVIDIA logo are trademarks and/or registered trademarks of NVIDIA Corporation in the U.S. and other countries.

    Wireless InSite System Requirements

    System Requirements

    Minimum
    Recommended
    Advanced
    Processor
    Intel i3
    Intel i7 or better
    Dual Intel Xeon
    Logical Processors [1]
    2
    4
    8+
    RAM
    8 GB
    16 GB
    64 GB
    GPU RAM
    2 GB
    6 GB
    12 GB
    Hard Drive Space
    500 GB
    1 TB
    2 TB

    [1] Performance typically improves with more cores (or logical processors); however, many systems with large numbers of logical processors have limitations on sustained peak utilization.

    [2] GPU must be a CUDA capable card and compatible with NVIDIA OptiX 4.1.0.  Based on the release notes for OptiX 4.1.0 and the timing of its release, CUDA capable cards with compute capability of 3.0 or higher should be supported.  Contact NVIDIA support for specific recommendations.

    XStream GPU Acceleration:

    • NVIDIA compute capability: 3.0 or higher [2]

    GUI - Supported Platforms:

    • Microsoft Windows 7, Windows 8, Windows 10, and Windows 11, 64- bit

    Computation Engine – Supported Platforms:

    • Microsoft Windows 7, Windows 8, and Windows 10, and Windows 11, 64- bit

    • Red Hat Enterprise Linux 6, 64-bit (and compatible systems)

    WaveFarer System Requirements

    System Requirements

    Minimum
    Recommended
    Advanced
    Processor
    Intel i3
    Intel i7 or better
    Dual Intel Xeon
    Logical Processors [1]
    2
    4
    8+
    RAM
    8 GB
    16 GB
    64 GB
    GPU RAM
    2 GB
    6 GB
    12 GB
    Hard Drive Space
    500 GB
    1 TB
    2 TB

    [1] Performance typically improves with more cores (or logical processors); however, many systems with large numbers of logical processors have limitations on sustained peak utilization.

    [2] GPU must be a CUDA capable card and compatible with NVIDIA OptiX 4.1.0.  Based on the release notes for OptiX 4.1.0 and the timing of its release, CUDA capable cards with compute capability between 3.0 and 6.1 should be supported.  Contact NVIDIA support for specific recommendations.

    XStream GPU Acceleration:

    • NVIDIA compute capability: 3.0 - 6.1 [2]

    GUI - Supported Platforms:

    • Microsoft Windows 7, Windows 8, and Windows 10, 64- bit
    • Red Hat Enterprise Linux 7, 64-bit (and compatible systems)

    Computation Engine – Supported Platforms:

    • Microsoft Windows 7, Windows 8, Windows 10, 64-bit
    • Red Hat Enterprise Linux 6 and 7, 64-bit (and compatible systems)
    • Inquire for other platform availability.

    The MPI module is available for the following platforms:

    • Open MPI on Red Hat Enterprise Linux 6 and 7, 64-bit (and compatible systems)
    • Inquire for other platform availability.

    XGtd System Requirements

    System Requirements

    Minimum
    Recommended
    Advanced
    Processor
    Intel i3
    Intel i7 or better
    Dual Intel Xeon
    RAM
    8 GB
    16 GB
    32 GB
    Hard Drive Space
    250 GB
    500 GB
    Solid State Drive
    XStream® GPU Acceleration
    NVIDIA CUDA capable card, compute capability 3.0 to 5.2. *
    NVIDIA CUDA capable card, compute capability 3.0 to 5.2. *
    NVIDIA CUDA capable card, compute capability 3.0 to 5.2. *
    GPU RAM
    2 GB
    5 GB
    12 GB

    GUI - Supported Platforms:

    • Microsoft Windows 7, Windows 8, and Windows 10, 64- bit

    Computation Engine - Supported Platforms:

    • Microsoft Windows 7, Windows 8, Windows 10, 64-bit
    • Red Hat Enterprise Linux 6, 64-bit (and compatible systems)
